Item

Parameter

Ethernet Port

1x 10Gbps RJ45 (DATA)

Fiber Port

1x 10Gbps SFP+

Console Port

1x console port

Reset Key

1

Bandwidth

40Gbps

Forwarding Rate

29.76Mpps

MAC

8K

Buffer

8.1Mbit SRAM Packet Buffer

Jumbo Frame

Jumbo frame up to 12KB

VLAN Address

4K

Function

Optical Watchdog: When abnormal light path is detected, restart the light module

Reach

100BASE-T: Cat5 or later UTP(≤150m)

1000BASE-T: Cat6 or later UTP(≤150m)

2500BASE-T: Cat6 or later UTP(≤100m)

5000BASE-T: Cat6 or later UTP(≤80m)

10000BASE-T: Cat6 or later UTP(≤30m)

SFP (Depending on the optical module):

Multi-mode Fiber: 550m/2km @10G

Single mode Fiber: 3km~120km @10G

LED

V1/V2/V3: Power Indicator

SYS: System Indicator

Fiber Dog -LED: Optical Watchdog

10G/2.5G: Optical Port Rate Indicator

RJ45: 2.5G/5G LED (Green)

10G LED (Orange)

Link/Act Indicator

Power Supply

Voltage input: DC12-57V

Consumption: ≤24W

Environmental

Working Temperature: -40℃~75℃

Working Humidity: 5%~90% RH (no condensing)

Storage Temperature: -40℃~80℃

Storage Humidity: 5%~95% RH (no condensing)

Mechanical

Product Size: 105mm*90mm*30mm

Packing Dimension: 202mm*133mm*40mm

Support Desktop or DIN installation

Net Weight

0.3kg

Surge

IEC 61000-4-5, ±6KV; IP30

Certification

CE-EMC EN55032; CE-LVD EN62368; FCC Part 15 Class B; RoHS

Warranty

1 year (Whole device, but Accessories not included)
