Item

Parameter

Ethernet Port

4x 10/100M/1000Mbps RJ45

Auto-Negotiation

Fiber Port

1x 10/100/1000Mbps SFP

Serial Port

1x RS485

Reach

≤100m @1000Base-T

≤250m @10Base-T

Protocol

IEEE802.3: Ethernet

IEEE802.3i: 10Base-Tx

IEEE802.3u: 100Base-Tx/Fx

IEEE802.3z: 1000Base-X

IEEE802.3ab: 1000Base-Tx

IEEE802.3x: Flow Control

IEEE802.1d: STP

Power Supply

Voltage input: DC12~55V

Consumption: 12W (12V1A)

Connector: Phoenix terminal block

Support Dual power redundancy

Environmental

Working Temperature: -40℃~85℃

Working Humidity: 0%~90% (no condensing)

Storage Temperature: -50℃~95℃

Storage Humidity: 0%~95% (no condensing)

Installation

DIN rail

Safety & Reliability

Surge: 1500W

ESD: IEC 61000-4-2, ±4kV (Contact & Air Discharge)

Lightning Surge: IEC 61000-4-5, ±4kV (Line-to-Earth)
